Description
Specification
| Technical specification | ||||||||
| Model | H36105 | H4850 | H48105 | H48150 | H48200 | H72105 | H72150 | H72210 |
| Nominal Voitage | 36V(38.4V) | 48V(51.2V) | 48V(51.2V) | 48V(51.2V) | 48V(51.2V) | 72V(76.8V) | 72V(76.8V) | 72V(76.8V) |
| Nominal capacity | 105Ah | 50Ah | 105Ah | 150Ah | 200Ah | 105Ah | 150Ah | 210Ah |
| Stored Energy | 4.03kwh | 2.56kwh | 5.37kwh | 7.68kwh | 10.24kwh | 8.06kwh | 11.52kwh | 16.12kwh |
| Dimension (LxWxH) | 15.8×13.3x 9.6 inch (401*334*245mm) |
18.1×13.1x 9.6 inch (460*334*245mm) |
18.5 x 13.1 x 19.6 inch (470*334*245mm) |
25.6×16.4x 9.8 inch (650*418* 250 mm) |
33.5×13.1x 9.8 inch 850*334*250mm |
25.6×13.1x 9.6 inch (650*335*245mm) |
32×16.4x 9.8 inch (812*418*250mm) |
32.9×16.7x 9.8 inch (835*425*250mm) |
| Weight lbs. (kg) | 80lbs (36.5kg) | 73lbs(33kg) | 100lbs(45.5kg) | 135lbs(61.5kg) | 179lbs(81.5kg) | 141lbs(64kg) | 215lbs(97.5kg) | 261lbs(118.5kg) |
| Typical Mileage per Full charge | 48-64 km (30-40 miles) | 35-48 km (20-30 miles) | 64-81 km(40-50 miles) | 97-113 km (60-70 miles) | 120-160 km(80-100miles) | 97-113 km(60-70miles) | 130-180 km(80-100miles) | 150-200 km(100-120miles) |
| Max Continuous Discharge | 100A | 50A | 100A | 150A | 200A | 100A | 150A | 200A |
| Max Discharge 3 Sec | 600A | 300A | 600A | 600A | 600A | 600A | 600A | 600A |
| Max Discharge 10 Sec | 250 A | 150 A | 250 A | 250 A | 250 A | 250 A | 250 A | 250 A |
| Operating Temperature | -4°F~131°F(-20°C~ 55°C) | |||||||
| Storage( 1 month ) | -4°F~113F(-20°C~45°C) | |||||||
| Storage( 1 year ) | 32°F~95°F(0°C~35°C) | |||||||
